Description
Metric
Imperial
Main Dimensions & Performance Data
| d | 220 mm | Bore diameter |
| D | 420 mm | Outside diameter |
| T | 122 mm | Height |
| Ca | 2,950,000 N | Basic dynamic load rating, axial |
| C0a | 11,500,000 N | Basic static load rating, axial |
| Cua | 1,000,000 N | Fatigue load limit, axial |
| nG | 900 1/min | Limiting speed |
| nϑr | 270 1/min | Reference speed |
| ≈m | 86.21 kg | Weight |
Dimensions
| D1 | 225 mm | Bore diameter housing washer |
| d1 | 420 mm | Rip diameter shaft washer |
| rmin | 6 mm | Minimum chamfer dimension |
Temperature range
| Tmin | -20 °C | Operating temperature min. |
| Tmax | 120 °C | Operating temperature max. |
Additional information
| K89444-M | Axial roller and cage assembly | |
| GS89444 | Housing Washer | |
| WS89444 | Shaft washer |
Characteristics
